Specifications
Model | ZJY1.0-6.0×1600(2000) | ZJY2.0-10.0×1600(2000) | ZJY3.0-12.0×2000 | ZJY4.0-16.0×2000(2500) | |
Coil Material | Cold-rolled Coil,Hot-rolled Coil,Stainless Coil,Galvanized Coil | ||||
Coil Thickness | 1.0~6.0mm | 2.0~10.0mm | 3.0~12.0mm | 4.0~16.0mm | |
Coil Width | 700~1600(2000) mm |
800~1600(2000) mm |
800~2000 mm |
800~2000(2500) mm |
|
Coil Weight | ≤25T | ≤25T(30T) | ≤30T | ≤30T | |
Coil I.D | Φ508mm Φ610mm Φ760mm |
Φ508mm Φ610mm Φ760mm |
Φ508mm Φ610mm Φ760mm |
Φ610mm Φ760mm Φ820mm |
|
Coil O.D | ≤Φ2000mm | ≤Φ2000mm | ≤Φ2000mm | ≤Φ2000mm | |
Strip Width | ≥55mm | ≥65mm | ≥85mm | ≥85mm | |
Number of Strip | 5~15 | 5~15 | 4~15 | 4~12 | |
Slitting Accuracy | ≤±0.25mm | ≤±0.25mm | ≤±0.3mm | ≤±0.3mm | |
Line Speed | 0~60m/min | 0~30m/min | 0~30m/min | 0~20m/min |
