Specifications
Model | JPY1.0-6.0×1600 | JPY2.0-1.0×2000 | JPY3.0-12.0×2000 | JPY4.0-16.0×2000 | JPY8.0-25.0×2500 |
Coil Material | δs≤230N/mm2,Hot-rolled Coil,Stainless Steel Coil | ||||
Coil Thickness | 1.0~6.0mm | 2.0~10.0mm | 3.0~12.0mm | 4.0~16.0mm | 8.0~25.0mm |
Coil Width | 800~1600mm | 800~2000mm | 800~2000mm | 1000~2100mm | 1000~2500mm |
Coil Weight | ≤25T | ≤25T | ≤30T | ≤30T | ≤40T |
Coil I.D | ф508mm, ф610mm, ф760mm |
ф610mm~ф820mm | ф610mm~ф820mm | ф610mm~ф820mm | ф610mm~ф820mm |
Coil O.D | ≤ф2000mm | ≤ф2000mm | ≤ф2000mm | ≤ф2000mm | ≤ф2200mm |
Cutting Range | 500~6000mm | 500~12000mm | 500~12000mm | 500~12000mm | 500~12000mm |
Cutting Accuracy | ±1.0mm | ±1.5mm | ±1.5mm | ±1.5mm | ±2.0mm |
Line Speed | 0~35m/min | 0~25m/min | 0~25m/min | 0~25m/min | 0~20m/min |
Electrical Control System | PLC Automatic control |
